생각공유 웹 서비스


Project 진행 시기: 2021/11/10 - 2022/01/03
REPOSITORY: https://github.com/Rick00Kim/Debate_project

BACKGROUND

국적불문하고 하나의 주제를 가지고 여러 사람이 의견을 공유하는 토론의 장이 있으면 어떨까?

혹은 자신의 고민거리를 여러사람에게 공유하여 공감을 받을 기회가 있으면 어떨까?

GOAL

자기생각을 자유롭게 공유할 수 있는 토론의 장을 웹 서비스로서 구축 및 관리

PRECONDITION

  1. Frontend, Backend 구분해서 모듈을 작성할것
  2. Container기술을 적극활용하여 구축할것

PROJECT FLOW

1. Infra & Stack

  1. Compute Instance (원격서버)

    Oracle Cloud Infrastructure 채용

    🪄 구축 및 관리방법은 Oracle Cloud Infrastructure 학습하기 참조

    ⚙️ 서버내 설치 툴

    1. Docker: Container 이용목적
    2. docker-compose: Docker이용 복수 Container 관리목적
      🔆 이후 복수 Container 관리는 Kubenetes 채용 예정
  2. Web server

    NGINX

  3. Database

    MongoDB

  4. Language & tool

환경구축
  1. 초기개발도구 환경설정내 이하 항목을 설치

    • Python
    • NodeJS
    • Yarn
    • Docker
    • Docker-compose
  2. 개발용 MongoDB 설치방법

    1. Dockerfile 작성

       1
       2
       3
       4
       5
       6
       7
       8
       9
      10
      11
      12
      13
      14
      15
      16

      FROM mongo

      # Environment variables for Initializing DB
      # Mongodb Global variables
      ENV MONGO_INITDB_ROOT_USERNAME 'dev_debate_admin'
      ENV MONGO_INITDB_ROOT_PASSWORD 'debate1234'

      # Environment variables
      ENV TARGET_DATABASE 'debate_web'
      ENV TARGET_USERNAME 'debate_manager'
      ENV TARGET_PASSWORD 'manDEV1234'

      # Copy Initialize file
      COPY ./init.sh /docker-entrypoint-initdb.d/

      EXPOSE 27017

    2. init.sh 작성

       1
       2
       3
       4
       5
       6
       7
       8
       9
      10
      11
      12
      13
      14
      15
      16
      17
      18
      19
      20
      21
      22
      23
      24
      25
      26

      #!/bin/bash
      set -e

      echo ">>>>>>> trying to create database and users"
      if \
      [ -n "${MONGO_INITDB_ROOT_USERNAME:-}" ] && \
      [ -n "${MONGO_INITDB_ROOT_PASSWORD:-}" ] && \
      [ -n "${TARGET_DATABASE:-}" ] && \
      [ -n "${TARGET_USERNAME:-}" ] && \
      [ -n "${TARGET_PASSWORD:-}" ]; then
      mongo -u $MONGO_INITDB_ROOT_USERNAME -p $MONGO_INITDB_ROOT_PASSWORD <<EOF
      db=db.getSiblingDB('$TARGET_DATABASE');
      use $TARGET_DATABASE;
      db.createUser({
      user: '$TARGET_USERNAME',
      pwd: '$TARGET_PASSWORD',
      roles: [{
         role: 'readWrite',
         db: '$TARGET_DATABASE'
      }]
      });
      EOF
      else
         echo "Not exists environment variables..."
         exit 403
      fi

    3. Docker image 생성 및 Run

      1. Set environment variables

        1
        2
        3
        4

        # Image name
        export mongoImageName=dev_debate_mongo_img
        # Container name
        export mongoContainerName=dev_debate_mongo

      2. Build

        1

        docker build -f DockerfileForMongo -t ${mongoImageName} .

      3. Run Container

        1

        docker run --name ${mongoContainerName} -p 27017:27017 --rm -d ${mongoImageName}


2. Design

화면 레이아웃(초판)

  1. Index

    초기화면

    layout-index
  2. Login

    로그인화면

    layout-login
  3. Signup

    회원가입화면

    layout-signup
  4. Main

    토론메인화면

    layout-main

API Endpoint

No Category End point Function name Method description
1 Auth /api/auth Authorize POST Login
2 Users /api/signup Sign up POST Sign up user
3 Users /api/users Get all users GET get all users (Manage)
4 Topics /api/topic Get topic GET Get all topics
5 Topics /api/topic/{topic_num} Get specific topic GET Get specific topic (Use path variable)
6 Topics /api/topic Resister topic POST Register new topic
7 Topics /api/topic Modify topic PUT Modify topic
8 Topics /api/topic/{topic_num} Delete topic DELETE Delete topic
9 Debates /api/debates/{topic_num} Get Debate List GET Get Debate list by topic
10 Debates /api/debates Resister Debate POST Register debate linked topic
11 Debates /api/debates/{debate_id} Delete Debate DELETE Delete specific debate
12 Debates /api/debates Modify Debate PUT Modify debate
13 Like /api/like/{debate_num} Get Like and Unlike GET Get like list and unlike list
14 Like /api/like Resister like POST Register like(Include delete)
15 Like /api/unlike Resister unlike POST Register unlike (Include delete)

3. Dockerize

  1. Web server, Frontend, Backend, DB 관리용 Dockerfile, docker-compose(yaml)을 작성

    • Project docker-compose: Link
      • NGINX Config file: Link
      • Dockerfile for Frontend : Link
      • Dockerfile for Backend: Link
      • Dockerfile for MongoDB: Link
  2. Automate Build and Deploy

    • github workflow 작성

    • docker repository 구축

CONCLUSION

  • Docker내 네트워크 설정에 대해 학습이 가능하였음
  • React 모듈내 Responsive 디자인 학습이 가능하였음
  • React 모듈내 Proxy관련 설정에 대한 학습이 가능하였음
  • CI/CD관련
    • Github actions를 통한 Oracle Cloud Infrastruct 연계학습

TODO

  • SP화면 수정(UX/UI관점 개선)
    Issue URL: issues-3
  • Dockerize and automating Release
    Pull request: pull request-9
  • 현재 Docker로 생성되어있는 모듈을 Microservice로의 Architecture 구상
  • Microservice내 변경이 이루어진 모듈만 이행이 가능하도록 학습
